Knocks FD.54 MAN Filter Regulator, 3/4" (Manual Drain) 0.5-16BAR 40µm
- Regular price
- $766.20
- Sale price
- $766.20
Good stock – Lead time 4-7 days
KNOCKS FD.54 MAN Filter Regulator is meticulously crafted in Germany with a metallic body and polycarbonate bowl. It features 3/4" port connections, manual drain, and 40µm filtration efficiency. With a maximum operating pressure of 16 bar, it finely regulates compressed air pressure within a range of 0.5-16 bar. Its compact design and high-quality construction ensure reliable performance in industrial machinery, automation, and fluid power applications.
| Port size | G 3/4 |
| Description | Air line regulator with diaphragm and relieving feature, centrifugal force principle with sintered filter |
| Mounting | Vertically, drain plug at bottom |
| Supply pressure | Pe max.16 bar Pe max. 12 bar with auto drain Pe min. 1,5 bar with auto drain |
| Reduced pressure | Pa 0,5-10 bar standard.0,1-3 bar, 0,5-6 bar, 0,5-16 bar |
| Filter element | 40 μm standard, 8 μm (absolutly) |
| Media and ambient temperature | Max. 60℃ (oth. temperature ranges available upon request) |
| Bowl volume | Max. 300 cm³ condensation volume |
| Drain model | Manual drain standard, optional semi and auto drain |
| Fixing | bracket |
