Knocks FD.12 MAN Filter Regulator, 3/8" (Self Drain)
- Regular price
- $126.80
- Sale price
- $126.80
Good stock – Lead time 4-7 days
The Knocks FD.12 Filter Regulator is a pneumatic device with a 3/8" port size designed to regulate air pressure. Constructed in Germany, it features a metallic chassis and a transparent polycarbonate bowl for ease of monitoring. The regulator mounts vertically and has a drain plug for manual drainage of condensed moisture. It operates within a supply pressure range of 0.5-16 bar and a reduced pressure range of 0.1-10 bar, with a filter element of 5μm. The bowl has a condensation volume capacity of 35 cm³.
| Port size | G 3/8 |
| Description | Air line regulator with diaphragm and relieving feature, centrifugal force principle with sintered filter |
| Mounting | Vertically, drain plug at bottom |
| Supply pressure | Pe max.16 bar |
| Reduced pressure | Pa 0,5-10 bar standard.0,1-3 bar, 0,5-6 bar, 0,5-16 bar |
| Filter element | 5 μm standard |
| Media and ambient temperature | Max. 60℃ (oth. temperature ranges available upon request) |
| Bowl volume | Max. 35 cm³ condensation volume |
| Drain model | Manual drain standard, optional semi drain |
| Fixing | Panel mounting, bracket |
