Knocks FD.12 AM10 Filter Regulator (Auto Drain)
- Regular price
- $151.80
- Sale price
- $151.80
Good stock – Lead time 4-7 days
The KNOCKS FD.12 AM10 Filter Regulator combines a filter and regulator in one convenient unit. Designed for pneumatic systems, it features a 3/8" port connection and an auto drain function that removes condensation from the bowl. Manufactured in Germany, this high-quality regulator ensures reliable performance. It operates with a maximum supply pressure of 16 bar, and its reduced pressure range can be customized from 0.1 bar to 16 bar. The filter element has a 5 µm pore size, effectively removing particles from the air supply. The bowl holds a maximum condensation volume of 35 cm³, and the regulator can be mounted vertically or with the drain plug facing downward.
| Port size | G 3/8 |
| Description | Air line regulator with diaphragm and relieving feature, centrifugal force principle with sintered filter |
| Mounting | Vertically, drain plug at bottom |
| Supply pressure | Pe max.16 bar |
| Reduced pressure | Pa 0,5-10 bar standard.0,1-3 bar, 0,5-6 bar, 0,5-16 bar |
| Filter element | 5 μm standard |
| Media and ambient temperature | Max. 60℃ (oth. temperature ranges available upon request) |
| Bowl volume | Max. 35 cm³ condensation volume |
| Drain model | Manual drain standard, optional semi drain |
| Fixing | Panel mounting, bracket |
