Knocks C.33 AM10 B Filter Regulator F/R 1/2", (Auto Drain), (with Bowl Guard)
- Regular price
- $256.90
- Sale price
- $256.90
Good stock – Lead time 4-7 days
The Knocks C.33 AM10 B Filter Regulator F/R is a 1/2" industrial machinery, automation, and fluid power product. It features an auto drain, bowl guard, and a panel mounting bracket. The technical specifications include a port size of G 1/2, a maximum supply pressure of 16 bar, a reduced pressure range of 0.5-10 bar, a filter element with a 5μm rating, and a maximum media and ambient temperature of 60°C. The product is manufactured in Germany and has an MPN of 9.2133.016.
| Port size | G 1/2 |
| Description |
Air line regulator with diaphragm and relieving feature, centrifugal force principle with sintered filter |
| Mounting | Vertically, drain plug at bottom |
| Media | Compressed air, neutral gases |
| Supply pressure | Pe max.16 bar Pe min. 1,5 bar with semi- and auto drain |
| Reduced pressure | Pa 0,5-10 bar standard.0,1-3 bar, 0,2-6 bar, 0,5-16 bar |
| Filter element | 5 μm standard, (absolutely) |
| Media and ambient temperature | Max. 60℃ (oth. temperature ranges available upon request) |
| Bowl volume | Max. 50 cm³ condensation volume |
| Drain model | Manual drain standard |
| Fixing | Panel mounting, bracket or through 2 holes in the body |
