Knocks C.22 HA3 B Filter Regulator F/R 3/8", (Self Drain)
- Regular price
- $174.10
- Sale price
- $174.10
Good stock – Lead time 4-7 days
The Knocks C.22 HA3 B Filter Regulator is a high-quality industrial product with a port size of G 3/8 and a filter element of 5 µm. It features a self-drain function, a bowl guard, and a supply pressure range of 1.5 to 16 bar. Its reduced pressure can be adjusted from 0.5 to 10 bar, 0.1 to 3 bar, 0.2 to 6 bar, or 0.5 to 16 bar. The filter regulator has a bowl volume of up to 40 cm³ and can be mounted vertically or through two holes in the body. It is suitable for use in environments with temperatures up to 60°C.
| Port size | G 3/8 |
| Description |
Air line regulator with diaphragm and relieving feature, centrifugal force principle with sintered filter |
| Mounting | Vertically, drain plug at bottom |
| Supply pressure | Pe max.16 bar Pe min. 1,5 bar with auto drain |
| Reduced pressure | Pa 0,5-10 bar standard.0,1-3 bar, 0,2-6 bar, 0,5-16 bar |
| Filter element | 5 μm standard, (absolutely) |
| Media and ambient temperature | Max. 60℃ (oth. temperature ranges available upon request) |
| Bowl volume | Max. 40 cm³ condensation volume |
| Drain model | Semi drain standard |
| Fixing | Panel mounting, installationdiameter Ø 42,5, bracket or through 2 holes in the body |
