Knocks C.22 AM10 B Filter Regulator F/R 3/8", (Auto Drain), (with Bowl Guard)
- Regular price
- $151.80
- Sale price
- $151.80
Good stock – Lead time 4-7 days
KNOCKS Filter Regulator F/R features a 3/8-inch port size and G3/8 auto drain, with bowl guard. This air line regulator operates with diaphragm and relieving feature based on centrifugal force principle with sintered filter. Suitable for vertical mounting, it has a maximum supply pressure of 16 bar, minimum supply pressure of 1.5 bar, and reduced pressure of 0.5-10 bar. The filter element has a standard size of 5 μm, and the bowl volume is 40 cm³. The semi drain model is standard, and the unit can be mounted via panel mounting, installation diameter Ø 42.5, bracket, or through 2 holes in the body.
| Port size | G 3/8 |
| Description |
Air line regulator with diaphragm and relieving feature, centrifugal force principle with sintered filter |
| Mounting | Vertically, drain plug at bottom |
| Supply pressure | Pe max.16 bar Pe min. 1,5 bar with auto drain |
| Reduced pressure | Pa 0,5-10 bar standard.0,1-3 bar, 0,2-6 bar, 0,5-16 bar |
| Filter element | 5 μm standard, (absolutely) |
| Media and ambient temperature | Max. 60℃ (oth. temperature ranges available upon request) |
| Bowl volume | Max. 40 cm³ condensation volume |
| Drain model | Semi drain standard |
| Fixing | Panel mounting, installationdiameter Ø 42,5, bracket or through 2 holes in the body |
