Knocks C.12 S AM10 B Filter Regulator (G3/8")
- Regular price
- $141.30
- Sale price
- $141.30
Good stock – Lead time 4-7 days
Knocks C.12 S AM10 B Filter Regulator is a German-made industrial product designed for precise air pressure regulation. Its features include a G3/8 port size, centrifugal force principle, and panel mounting with a bowl guard. The regulator can handle a maximum supply pressure of 16 bar and a minimum of 1.5 bar, while the reduced pressure can be adjusted between 0.5 and 10 bar. It comes with a 5µm sintered filter element and can drain condensation manually or via an automatic drain. The device can be mounted vertically with the drain plug at the bottom and is compatible with bracket mounting or two-hole body mounting.
| Port size | G 3/8 |
| Description |
Air line regulator with diaphragm and relieving feature, |
| Mounting | Vertically, drain plug at bottom |
| Supply pressure | Pe max.16 bar Pe min. 1,5 bar with auto drain |
| Reduced pressure | Pa 0,5-10 bar standard.0,1-3 bar, 0,2-6 bar, 0,5-16 bar |
| Filter element | 5 μm standard, (absolutely) |
| Media and ambient temperature | Max. 60℃ (oth. temperature ranges available upon request) |
| Bowl volume | Max. 25 cm³ condensation volume |
| Drain model | Manual drain standard |
| Fixing | Panel mounting, bracket or through 2 holes in the body |
