Knocks C.12 HA4 B Filter Regulator (G3/8")
- Regular price
- $144.80
- Sale price
- $144.80
Good stock – Lead time 4-7 days
KNOCKS C.12 HA4 B Filter Regulator is designed for the industrial machinery, automation, and fluid power industries. This German-made filter regulator features a semi-drain and 3/8" port connections. Its diaphragm and centrifugal force principle with sintered filter effectively regulates air pressure. The bowl guard ensures safety while the 5 µm filter element (absolute) provides excellent filtration. The filter regulator can be mounted vertically, with its drain plug conveniently located at the bottom for easy maintenance.
| Port size | G 3/8 |
| Description |
Air line regulator with diaphragm and relieving feature, |
| Mounting | Vertically, drain plug at bottom |
| Supply pressure | Pe max.16 bar Pe min. 1,5 bar with auto drain |
| Reduced pressure | Pa 0,5-10 bar standard.0,1-3 bar, 0,2-6 bar, 0,5-16 bar |
| Filter element | 5 μm standard, (absolutely) |
| Media and ambient temperature | Max. 60℃ (oth. temperature ranges available upon request) |
| Bowl volume | Max. 25 cm³ condensation volume |
| Drain model | Manual drain standard |
| Fixing | Panel mounting, bracket or through 2 holes in the body |
