Univer E-0220D
- Regular price
- $499.00
- Sale price
- $499.00
Good stock – Lead time 4-7 days
The Univer E-0220D is a miniature valve with a five-port, two-position design. It can be mounted onto a sub-base or with a threaded body in M5 size. The valve is available in three different configurations: center closed, center open, or parallel closed. It is designed to handle pressures up to 10 bar and has a nominal flow rate of 150 Nl/min. The valve body is made of zamak and the seals are made of NBR. The valve can be actuated with DC or AC voltage, and it includes an electropilot and a U05 series coil.
| Series | Type | Control 14 | Return 12 |
| E=COMPA 2 Miniature valves | 02=5/2 Sub-base mounting 04=5/2 Threaded body M5 05=5/3 c.c. Sub-base mounting 06=5/3 o.c. Sub-base mounting 07=5/3 p.c. Sub-base mounting 08=5/3 c.c Threaded body M5 09=5/3 o.c. Threaded body M5 10=5/3 p.c. Threaded body M5 |
2=Electrical DC 4=Pneumatic 7=Electrical DC/AC |
0=Pneumomechanical spring 2=Electrical DC 4=Pneumatic impulse 7=Electrical DC/ACÂ |
