Univer CM-420 Spool Valve
- Regular price
- $219.40
- Sale price
- $219.40
Good stock – Lead time 4-7 days
The Univer CM-420 Spool Valve is a universal valve designed for industrial machinery, automation, motion control, and fluid power applications. It features a G1/8 or G1/4 connection and manual push-pull operation. Its die-cast zamak or aluminium body, nitrile rubber seals, and aluminium spool provide durability. The valve operates on 50 μm filtered air with or without lubrication. It includes an electropilot/coil (AA Series/U1-U3), AM5110 connector, and two-position screw for manual override. The CM-420 has a nominal bore ranging from 6.5 to 8.5mm and a nominal flow rate of 890 to 1480Nl/min.
|  Ambient temperature | -10÷45℃ |
| Fluid | 50 μm filtered air, with or without lubrication |
| Commutation system | Spool |
| Valve Body | die-cast zamak (G 1/8), aluminium (G 1/4) |
| Seals | Nitrile rubber |
| Spool | Aluminium |
| Electropilot / Coil | AA Series / U1-U3 |
| Power Consumption | 3,5 W (DC)-5 VA (AC) |
| Connector | AM5110 |
| Voltage | 12VDC-24VDC-24VAC-110VAC-230VAC |
| Manual Override | Two-position screw |
