Univer CM-410A Spool Valve

The Univer CM-410A Spool Valve is a universal valve with a nominal bore of 6.5 mm or 8.5 mm and a nominal flow rate of 890 to 1480 Nl/min. It has indirect mechanical operation for pneumatic and mechanical operators. The valve body is made of die-cast zamak (G 1/8) or aluminium (G 1/4), and the seals are made of nitrile rubber. The spool is made of aluminium and the electropilot/coil is AA series/U1-U3 with a power consumption of 3.5 W (DC) or 5 VA (AC). The valve has a G 1/8 or G 1/4 connection and a two-position screw manual override.
