Pneumax T514.52.00.39.B09 G1/4 5/2 Techno NAMUR Sol/Spring Valve 24Vdc 2 Watt

Pneumax T514.52.00.39.B09 is a 5/2 monostable pneumatic valve designed to control compressed air with a nominal flow rate of 1100l/min. It operates within an ambient temperature range of -10…50 Degrees and operates with a pressure range of 0…10bar. The valve conforms to the NAMUR standard and features an inline mounting style with a G1/4 pneumatic connection. It has a plug pattern type B electrical connection (EN 175301-810), utilizes 24V DC control voltage, and consumes 2W of power. The non-detenting manual override allows for manual operation, while the mechanical spring reset mechanism ensures reliable valve operation. The valve is part of the Series T514 range and is sold in packs of 1 in the United States of America.
