Pneumax 345.M17 3/2 NC Tube Ø 4 24/50

The Pneumax 345.M17 is an inline-mounted 3/2 normally closed poppet seat valve. It operates on compressed air at pressures between 0 and 10 bar with a nominal flow rate of 53 l/min. The valve has a nominal size of 1.3 mm, a 4 mm push-in pneumatic connection, and an electrical connection with a plug pattern type B. It operates at 24V AC 50 Hz and has a mechanical spring reset. The valve is part of the Series 300 and is sold in the United States of America in packs of one.
