Univer KD2001000150M Pneumatic Cylinder
- Regular price
- $525.20
- Sale price
- $525.20
Good stock – Lead time 4-7 days
The Univer KD2001000150M Pneumatic Cylinder is part of the KD-series ISO 15552 Pneumatic Cylinders designed with advanced specifications. It features a heavy-duty tube made of chromium-plated steel and a standard D.A piston rod. With a bore of 100 mm and a stroke of 150 mm, this pneumatic cylinder is equipped with a magnetic version for enhanced performance. It operates within an ambient temperature range of -20 to 80 degrees Celsius and utilizes filtered air or lubricated air.
| Ambient temperature | -20÷80℃ |
| Fluid | filtered air, with or without lubrication |
| Working Pressure | 1,5÷10 bar |
| End-caps | die-cast aluminium |
| Barrel | anodized aluminium |
| Piston | die-cast aluminium |
| Guide slide | acetalic resin |
| Piston rod | chromium-plated steel, stainless steel upon request |
| Piston seals | Â NBR |
| Guide bush for piston rod | UNIVER original self-lubricating and self-aligning |
| Shock absorber seals | NBR |
| Cushionings | pneumatic adjustable |
| Other available versions | tandem, two position tandem, opposed, with common piston rod |
