Mindman MVSC-220-4E1 AC110V Solenoid Valve 5/2 1/4"

Regular price: $44.70
Sale price: $44.70

Fully in Stock

The MINDMAN MVSC-220-4E1 AC110V Solenoid Valve is a 5/2 solenoid valve with a 1/4" port size. It has a low wattage AC110v coil and connector, and operates within a pressure range of 0.2~0.8 MPa. The MVSC-220-4E1 has an effective orifice of 18 mm² and a response time of 30 ms. It operates within an ambient temperature range of -5 ~ + 50°C.

Model	4E1
Bore no.:	8AÂ
Port size	Rc 1/4Â
No. of port	5
No. of position	2
Medium	Air
Operating pressure range	0.2~0.8 MPaÂ
Proof pressure	1 MPa
Ambient temperature	-5 ~ + 50â„ƒ (No freezing)
Effective orifice	18 mmÂ²
Reponse time	30 ms
Voltage	AC110V, 220V (50/60)Hz, DC24V
Power consumption	AC=4.8/4.4VA, 6/4.9VA, DC=2W
Available voltage range	Â± 10%
